Building realistic electric transmission grid dataset at scale: a pipeline from open dataset

At a glance - We construct geographically grounded, electrically coherent power grid models entirely from publicly available data and release a dataset spanning 48 U.S. states and multi-state interconnections. - The models support AC optimal power flow (AC‑OPF) analysis, enabling physics-based study of congestion, capacity, and demand siting without restricted data. - We demonstrate applications including transmission expansion potential, targeted line upgrades, and placement of large datacenter loads. Microsoft Research is excited to release an open dataset of approximate transmission topology of the U.S. power grid derived from publicly available data. The ability to study transmission-level power grid behavior is essential for modern power systems research. Analyses of congestion, transmission expansion, demand growth, and system resilience all depend on network models with realistic topology, electrical parameters, and geographic grounding. In most of the world, including the United States, realistic transmission-level grid data is classified as critical infrastructure information and subject to strict access controls. These restrictions exist for good reasons, but the resulting lack of realistic grid models is increasingly exacerbating the challenges power systems face. Decisions about where new load can be added – and how additional transmission assets can be deployed to support it – are often gated behind lengthy and opaque processes that can take years. For researchers developing new tools and algorithms, access typically requires long approval cycles, strict non-redistribution agreements, or costly commercial licenses. As a result, many are left choosing between small “toy” networks with dozens of buses, or synthetic models that do not correspond to real infrastructure. This lack of realistic, shareable models is particularly limiting for data-driven and AI-based approaches, which require large volumes of physically plausible grid data for training and evaluation methods for grid analysis and planning. Against this backdrop, a natural question arises: Can we meaningfully understand how the U.S. power grid responds to modern stresses – and facilitate the development of actionable solutions for the system – using only open data? In this work, we introduce an open-data-derived pipeline for constructing large-scale, transmission-level power grid models that realistically approximate existing networks without relying on proprietary or restricted datasets. We provide an open dataset derived from this process, consisting of transmission-level models spanning 48 U.S. states as well as interconnection-scale networks, ranging in size from small systems with as few as 11 buses to the full Eastern Interconnection grid connecting 21,697 buses. The pipeline has been validated across the continental United States, where sufficient open geographic, energy, and demographic data are available, and is designed to generalize to other regions with comparable public data sources. Using only publicly accessible datasets, the pipeline produces geographically grounded, electrically coherent transmission models at state, multi-state, and interconnection scales. These models preserve the geographic structure of transmission corridors, substations, and generators inferred from open data, while explicitly accounting for uncertainty where detailed operational parameters are unavailable through transparent feasibility reporting. Importantly, these are not toy networks or abstract benchmarks. The resulting models support alternating current optimal power flow (AC-OPF) analysis across a wide…
